Motor Grader GR200

Shangchai engine 147kW,
Operating weight 16 tons ,
Moldboard 4710×610mm,
Cabin with Air conditioner.
Adopt imported hydraulic parts .
Great working performance .
Various implements available
Model GR200GR220
Basic specification

Engine model6CTAA8.3   D6114SC9DK220.1G3
Rated power/speed138kW/2200    140kW/2300rpm    162kW/2000rpm
Dimension(LxWxH)8900×2625×3470mm8970×2625×3420mm
Operating weight(Standard)15400kg16500kg
Performance specification

Travelling speed ,forward5,8,11,19,23,38   km/h5,8,11,19,23,38   km/h
Travelling speed ,reverse5,11,23   km/h5,11,23   km/h
Tractive force(f=0.75)79KN85KN
Max. gradeability20%25%
Tire inflation pressure260   kPa260   kPa
Working hydraulic pressure16   MPa16   MPa
Transmission pressure1.3~1.8MPa1.3~1.8MPa
Operating specification

Max. steering angle of front wheels±50°±50°
Max. lean angle of front wheels±17°±17°
Max. oscillation angle of front axle±15°±15°
Max. oscillation angle of balance box1515
Frame articulation angle±27°±27°
Min. turning radius using articulation7.3m7.3m
Blade

Maximum lift above ground450mm450mm
Maximum depth of cutting500mm500mm
Maximum blade position angle90°90°
Blade cutting angle28°—70°28°—70°
Circle reversing rotation360°360°
Moldboard width X height3965×610mm4270×610mm
